Factory Supply Good Quality 50t/24h Maize Milling Machine

   Factory supply good quality 50T/24H maize milling machine

  50T/24H maize milling machine can produce super white and fine maize flour, maize grits, maize rice depend on needing, and it's a much professional maize mill machine for industrial production. We have vertical design and horizontal design depend on client warehouse condition or final needing.

  50T/24H maize milling machine

Capacity Process 50T maize in 24Hours
Product type maize grits, maize flour, maize bran;
Product yield maize grits: about 45-55%,
maize flour:  about20-30%;
maize bran: 25% or so;
maize grits and maize flour total yield: 70-80%
Sand content in final product not more than 0.002g/kg;
Magnetic metal content not more than 0.003g/kg;
Water preservable 13.5-14.5%
Fat content 0.5-1%


  The maize mainly have three parts: germ, bran and Endosperm.

  Endosperm is mainly for get fine maize product, like maize flour, maize grits maize rice and so on.

  Germ and peel are mainly by-products with for animal feeding

  From maize to fine products, it need though cleaning system to clean maize well and degermintor remove all germ and peel from maize, to get cleaned and well Endosperm to prepare produce good quality maize final products. then the endosperm go to milling section to mill it in to flour /meal /grits/ rice depend on designing.

50T/24H maize milling machine

  1. Cleaning part:

  To clean out the middle and small impurity from wheat. e.g., dust, stone, magnetic material, maize was bitten by insect and so on.Includes beating, screening, destoner, magnetic separator and dampening. This section is make the maize/corn to prepare for milling part and to protect the machinery as well.

  2. Milling part:

  Include different number of mill and sifter to mill the wheat and separate the flour and bran

  (1) Mill: mill the wheat to break the integrity by the roller moving

  (2) Sifter: to separate the flour and bran, also separate large size and small size to ensure flour quality.

  3. Packing part:

  The packing part can be manual one also can be auto one, this can be designed according to requirement and machine capacity.

  4. PLC controlling system:

  To control the whole set of machinery to work well and showing the process of working

50T/24H maize milling machine

  We can supply turn key project of 5-1000T/D flour milling machine, with excellent quality, competitive price and best after-sales service.

  1. Roller mills manufactured precisely and controlled by manual or pneumatic mode. It can make better grinding effect compared with other ordinary mills.

  2. Complete set of flour mill adopt various configuration modes for different choices. There are streamlined design, reasonable layout, and good performance. It can be installed on steel structure or in building.

  3. The flour mill is with advanced technical process and flexible adjustment. It can produce grade flour and special flour.

  4. Perfect after-sales service is also supplied for all the machines.

  5. We arrange engineers to help install the machine, which can ensure the machine operate efficiently.
